TS450 Thermal Imaging Gun Sights With 400*300 IR Resolution And 50mm Focus Length

Product Details:

Place of Origin:	China
Brand Name:	OEM, ODM All Available
Certification:	CE,FC,RoHS

Payment & Shipping Terms:

Minimum Order Quantity:	10
Delivery Time:	3~7
Payment Terms:	T/T. L/C, Western Union, Money Gram
Supply Ability:	30000PCS/Month

Contact Now

Detailed Product Description

Type:	Rifle Scope	Size::	2309075mm
Weight::	≤660g	Magnification:	3.3~13.2X
Focal Length::	50mm	Frame Rate::	50Hz
IR Detector:	400*300 @17μm, Vox	Effective Visual Distance:	3000 Meters
High Light:	TS450 Thermal Imaging Gun Sights , 50mm Focus Thermal Imaging Gun Sights , 400x300 IR Thermal Imaging Rifle Scope

TS450 Thermal Imaging Gun Sights With 400*300 IR Resolution And 50mm Foucus Length

Parameter:

Model	TS425	TS435	TS450
Detector
Detector Type	400×300 @17μm, VOx
Spectral	8μm～14μm
NETD	≤50mk
Lens
Focal Length	25mm F1.1	35mm F1.2	50mm F1.2
Focusing	Manual Focus
FOV	14.9°×11.2°	10.7°×8.0°	7.5°×5.6°
Display
Display	Color 0.39-inch OLED Display, 1024×768
Eyepiece	Exit pupil distance 48mm, eyepiece magnification 14×
Magnification	1.6~6.4×	2.3~9.2×	3.3~13.2×
Video Output System	PAL 50Hz
External Video Display	Full color video output by external interface, with menu
Imaging
Frame Rate	50Hz
Digital Zoom	2×,4×
Color Palettes	White Hot, Black Hot, Red Hot 1, Red Hot 2, Red Hot 3, Green Hot, Blue Hot
Picture-in-picture	On/off,the position is adjustable
Functions
hotspot tracking	Yes
Compensation Modes	Auto Compensation / Shutter Compensation / Scene Compensation
Calibration	25m/50m/100m
Stadiametric rangefinder	1.8m/0.5m/0.25m
Gun Types Selection	6 Types
Power Supply
Battery Type	Interchangeable Li-ion battery 18650 x 1, Non-rechargeable on the device
Battery Operating Time	≥3H(Standard low temp battery,Observation status only)
	≥5H(Panasonic 3400mah standard 18650 battery,Observation status only)
Interface
Video Interface	Lemo
Environmental Characteristics
Operating Temperature	-40°C-50°C
Shock	500G/1ms
Encapsulation	IP67
Certificate	RoHS,CE
Weight & Dimensions
Weight(excl battery)	660g	660g	720g
Dimensions	230mm×90mm×75mm	230mm×90mm×75mm	250mm×90mm×75mm
Package Contents
Standard	Lens cap,battery,Charger,Video cable, Pick-up gun rack,Hard transport case,User Manual
Detection Range
Human:1.8m×0.5m	700m	1000m	1400m
Vehicle:2.3m×2.3m	1700m	2400m	3000m
Recognition Range
Human:1.8m×0.5m	350m	500m	700m
Vehicle:2.3m×2.3m	700m	1000m	1400m

Features:

1 With a 400x300 pixel TEC metal-encapsulated thermal detector, it can detect further distances and capture sharper, vivid images.

2. The TS thermal sight also has the characteristics of small size, waterproof and dustproof, strong shock resistance, strong and durable, and can perform well in any bad weather.
